EVOS
®
FL and EVOS
®
FL Color User Guide
11
Specifications
Optics
Infinity-corrected optical system; RMS-threaded objectives with 45 mm parfocal distance
Objectives
Objectives included vary per order. Contact Technical Support (see page 54) for a full list
of objectives supported.
Objective
Turret
5-position; front-mounted control
Light Cubes
Light cubes included vary per order. Specifications for our most popular light cubes are
listed below. Contact Technical Support (see page 54) for a full list of LED light cubes
supported.
• DAPI: 360 nm excitation, 447 nm emission
• GFP: 470 nm excitation, 525 nm emission
• RFP: 530 nm excitation, 593 nm emission
Illumination
LED (50,000-hour life); adjustable intensity
Contrast
Methods
Fluorescence and transmitted light (brightfield and phase contrast)
Condenser
Includes 3-position with brightfield and phase contrast annuli
Condenser
Working
Distance
60 mm
Mechanical
“Glide” Stage
XXY axis fine-positioning controls;
28.3 mm (1.11”) per rotation.
110 mm × 110 mm (4.3” × 4.3”) range of
motion
XXZ-axis focusing controls,
480 µm/rotation. XX-Interchangeable vessel
holders available for most common shapes
and sizes
LCD Display
15” color, 1024 × 768 pixels; adjustable tilt
Acquisition
Onboard microprocessor; built-in software for image acquisition via mouse control
Camera
Monochrome:
Sony ICX445 monochrome CCD,
1/3” 1280 × 960, 1.3 Megapixels
Color:
Sony ICX285AQ color CCD,
2/3” 1360 × 1024, 1.4 Megapixels
Captured
Images
Monochrome camera:
16-bit monochrome TIFF or PNG (12-bit
dynamic range);
24-bit color TIFF or PNG; jpeg, bmp
(1280 × 960 pixels)
Color camera:
16-bit color TIFF or PNG (12-bit dynamic
range);
24-bit color TIFF or PNG; jpeg, bmp
(1360 × 1024 pixels)
Output Ports
3 USB and 1 DVI (digital output)
Power Supply
AC Adapter; Input 100-240V, 50-60Hz; Output 12 VDC/4.15A
Dimensions
Operating height: 57.8 cm (22.75”)
Storage/transport height: 32.4 cm (12.75” )
Depth: 47.0 cm (18.5”); Width: 35.5 cm (14.0”)
Weight
15.3 kg (33.7 lbs)
