FL Color User Guide
1. Quick Reference Diagrams
Hardware Controls
Figure 1 FL footprint
Power Input Jack Y-Axis Stage Brake
Power Switch Focusing Knobs
USB and DVI Ports Objective Selection Wheel
Coarse Stage Positioning Knobs Light Cube Selection Lever
Stage X-Axis Knob Phase Annuli Selector
X-Axis Stage Brake Condenser Slider Slot
Stage Y-Axis Knob
