EVOS
®
FL and EVOS
®
FL Color User Guide
41
Software Interface Issues
We recommend keeping your EVOS
®
FL Imaging System up to date with the latest software. See “Updating
Software” (page 36) for more information.
Problem Possible Solutions
Image does not respond to changes in
focus or stage position
• Click the LIGHT ON button (note that a red USB icon on the
Save button indicates there is an unsaved image, which will
be lost unless it is saved before clicking LIGHT ON).
LIGHT ON/OFF button is inactive
• Verify that the light cube selection lever is clicked into a
position.
• Verify that the objective selection wheel is clicked into a
position.
Scalebar does not appear when clicked
• Capture image first; scalebar is only available after capturing
an image.
Save button does not respond when
clicked
• Click capture first; it is only possible to save an image that is
captured. The USB icon on the Save button is red when there
is a captured image to save.
DVI output does not work on an
external LCD monitor or projector
• Power the instrument off, check the cable connections, and
power on the instrument.
• Verify that the external display accepts DVI-D input (i.e.,
digital input). A monitor with analog input only (DVI-A) will
not display the digital output from EVOS
®
.
Unable to connect to network
• Verify physical cable connections; confirm the Ethernet jack is
active.
• Use a compatible network adapter.
• If the physical connections are good, and the problem persists,
contact your network administrator to resolve any network
issues. Note that a Linux network must use Samba for EVOS
®
to be able to find it.
