ApexRp Operators Manual
27 248083480-1 Rev 3
Figure 3-8 ApexRp Default Settings
Default Alarm Threshold settings are the same as all ApexRp models:
Ch1 threshold = 1000, Ch2 threshold = 1000 and channel alarms are
disabled. If the Alarm is enabled, the Alarm LED will turn on solid
green until that Alarm’s threshold value is exceeded, in which case
the LED will turn red.
Get IP Address, Subnet and Gateway from IT group.
(Factory defaults shown here)
To Next Page
