ApexRp Operators Manual
61 248083480-1 Rev 3
Additional status bits are shown in 40056 displayed in Table A-6.
Bit
Description
0
ApexRp: LASER POWER STATUS: Set to 1 when unit’s LASER
current is out of spec, else set to 0
1
ApexRp: LASER CURRENT STATUS: Set to 1 when unit’s
LASER power is out of spec, else set to 0
2
ApexRp: LASER SUPPLY STATUS: Set to 1 when unit’s LASER
supply is out of spec, else set to 0
3
ApexRp: LASER LIFE STATUS: Set to 1 when unit’s LASER
supply is out of spec, else set to 0
4
ApexRp: NO FLOW STATUS: Set to 1 when unit’s flow is below
no flow threshold causing LASER to turn off, else set to 0.
5
ApexRp: PHOTOAMP SUPPLY STATUS: Set to 1 when unit’s
photo amp supply is out of spec, else set to
6
ApexRp: BACKGROUND STATUS: Set to 1 when unit’s photo
amp background is out of spec, else set to 0
7
ApexRp: PHOTODIODE STATUS: Set to 1 when photodiode has
failed, else set to 0
8
ApexRp: CALIBRATION DUE DATE STATUS: Set to 1 when
unit is past calibration due date, else set to 0
9
ApexRp: LOCATION BRACKET STATUS: Set to 1 when unit is
in location bracket mode and bracket is missing, else set to 0.
Table A-6 Device Status (40056)
