Lighthouse Worldwide Solutions ApexR3p User Manual

ApexRp Operators Manual
67 248083480-1 Rev 3
Register
Data Type
Description
30001
signed integer
Timestamp [high] (# of seconds since midnight,
1/1/1970)
30002
signed integer
Timestamp [low]
30003
unsigned integer
Sample Time [high] (In seconds)
30004
unsigned integer
Sample Time [low]
30005
signed integer
Location [high] (Place where data was recorded)
30006
signed integer
Location [low]
30007
unsigned integer
Sample Status [high]
30008
unsigned integer
Sample Status [low]
30009
unsigned integer
Particle Channel 1 [high]
30010
unsigned integer
Particle Channel 1 [low]
30011
unsigned integer
Particle Channel 2 [high]
30012
unsigned integer
Particle Channel 2 [low]
30013
unsigned integer
Particle Channel 3 [high]
30014
unsigned integer
Particle Channel 3 [low]
30015
unsigned integer
Particle Channel 4 [high]
30016
unsigned integer
Particle Channel 4 [low]
...
30041
IEEE Float
Analog Channel 1 [high]
30042
IEEE Float
Analog Channel 1 [low]
30043
IEEE Float
Analog Channel 2 [high]
30044
IEEE Float
Analog Channel 2 [low]
30045
IEEE Float
Analog Channel 3 [high]
30046
IEEE Float
Analog Channel 3 [low]
30047
IEEE Float
Analog Channel 4 [high]
30048
IEEE Float
Analog Channel 4 [low]
...
30063
IEEE float
LASER Supply [low]
30064
IEEE float
LASER Supply [high] (percentage based on LASER
Supply Reference Value.
30065
IEEE Float
Background Voltage [low] (percentage based on
Calibration reference value) - ApexRp
30066
IEEE Float
Background Voltage [high]
…
30069
IEEE Float
LASER Voltage [low] (Percentage based on LASER
Reference value)
30070
IEEE Float
LASER Voltage [high]
Table A-13 Data Registers
