Lighting Controls Blue Box LT Series User Manual

LCDBBDICIG03Sept08
AUTO-ASSIGNING ADDRESSES TO A NEW DEvICE
Auto-addressing any newly added digital device (switch,
relay panel, DI Card, etc.) to any system with a Blue Box
LT Master Panel is done as follows:
After completing the product installation guide(s), 1.
power up all Slave Panels and active devices first and
then power up the Master Panel.
The main screen will be displayed for a few seconds, 2.
after which the screen below will be displayed. TAB
to YES and press ENTER to auto-address the new
device(s). If the number of devices detected does
not match the number of devices present on the bus,
proceed to troubleshooting section.
Found 1 device on the system that are
not used.
Would you like to auto-assign them?
YES / NO / ->
Never Ask Again
To view address assignment, TAB to YES and press 3.
ENTER to go to the “Serial Number Scan” screen.
Assigned 1 device.
Review assignments by
scanning all serial numbers?
YES / NO
If adding more than one device, TAB to “Serial#” field 4.
and SCROLL UP or DOWN to review each device.
SCAN by serial#
Serial# CE80
Adr: 1
Item Type: Switch
Mapd: 6 Btn. Switch
Address: OK
SAVE ADDRESS CHANGES
Add the new device(s) to the “System Device Sched-5.
ule” on the back of the “Panel Schedule” located inside
The Blue Box LT Master Panel for future programming.
LIGHTING CONTROL & DESIGN
905 Allen Ave • Glendale, CA 91201 • Support 800-345-4448 • www.lightingcontrols.com
FOR MASTER
PANELS ONLY
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
Device Type
Location
Serial #
Address
SYSTEM DEVICE SCHEDULE: (for Master Panels Only)
LIGHTING CONTROL & DESIGN
905 Allen Ave s Glendale, CA 91201s Support 800-345-4448 s www.lightingcontrols.com
(Master) LCP1
1
L
C
DBBIG13Au
g
0
8
BB Panel Schedule.indd 4 8/13/2008 1:37:47 PM
3 btn sw
Hallway
8875
3
6 btn sw
lobby
4685
4
DI-6
LCP 1
4055
7
LCP 2
telecom
af97
5
(Master) LCP1
elec rm
ce80
1
Not sure what the serial numbers are? Each device 6.
has a unique Serial Number label or do the following
to “read” the Serial Number from the DTC clock:
Navigate to the “Read Address” screen: USER MENU 7.
> SETUP MENU > RESTRICTED > ADDRESSING-
BUS SCAN > READ ADDRESS. The password to
enter the RESTRICTED area is 900001.
Press the first button on a switch or the “Address/Assign” 8.
button. The screen will display the “Address” and “Se-
rial number”. Record this data on the “System Device
Schedule. “ The system is now ready for Error Checking.
EXIT repeatedly to navigate to the main menu.
ERROR CHECk
Navigate to the Error Statistics Screen. Use the path 9.
USER MENU > SETUP MENU > RESTRICTED >
ADDRESSING-BUS SCAN > ERROR STATISTICS.
Tab to the field that says CLEAR and press ENTER to 10.
clear errors. If after 3 minutes no errors accumulate
on this screen, your system is stable.
If errors continue to accumulate, refer to the “Error 11.
Check Troubleshooting” section in the Blue Box LT
“O&M Manual” or “System Start-Up Cabling Guide”
or call Technical Support: 1-800-345-4448.
The “Serial Num-
ber Scan” screen
displays the serial
number, address,
and device-type
of any newly
added device(s)
