Lighting Controls Blue Box LT Series User Manual

70 THE BLUE BOX LT PROGRAMMING
LCDBBP03Sept08
MANUAL CONTROL OF RELAYS
Manually control and visually check the (on/off) status
of any relays(s) in any panel(s).
To Start
TAB once or twice to get started. The USER 1.
MENU will display.
TAB to MANUAL OVERRIDE.2.
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
ENTER to select the MANUAL CONTROL screen.3.
To Navigate to a LOAD (Relay)
MANUAL CONTROL AU
LCP-1 LOAD-1
1- 3■ 5■ 7■ 9- 11- 13- 15-
2- 4- 6- 8■ 10- 12- 14- 16-
SCROLL to select LCP
TAB to LOAD
SCROLL to select LOAD
ENTER to toggle status
TAB to LCP-1(Lighting Control Panel 1).4.
SCROLL to select the correct LCP (for systems 5.
with multiple LCPs).
TAB to LOAD-1.6.
SCROLL up or down to select the LOAD (relay) 7.
to control.
To Control a LOAD (Relay):
ENTER to toggle the status of the LOAD “off ” 8.
or “on”.
MANUAL CONTROL AU
LCP-1 LOAD-1
1■ 3■ 5■ 7■ 9■ 11- 13- 15■
2- 4- 6- 8■ 10- 12- 14- 16-
LOAD 15 is on. .
LOAD 16 is off.
- indicates the LOAD is off
■ indicates the LOAD is on
There are other relays statuses. Refer to “Groups
FAQ” for a more complete description of all of the
different relay statuses.
MANUAL CONTROL AU
LCP-1 LOAD-1
1■ 3■ 5■ 7■ 9- 11- 13- 15-
2- 4- 6- 8■ 10- 12- 14- 16-
AU indicates LCP 1 is
in AUTOMATIC mode.
“MN” indicates LCP 1
is in HAND mode
Press EXIT several times to get back to the main 9.
screen.
