Lighting Controls Blue Box LT Series User Manual

THE BLUE BOX LT PROGRAMMING 73
LCDBBP03Sept08
TIME SCHEDULES
Introduction to Time Schedules
There are a few important things to note before
programming a Time Schedule:
Time Schedules DO NOT control relays – they
control Groups and have Scheduled Events (when
things are on and off). Groups contain Loads (relays)
and describe “behaviors” pertaining to the schedule.
For more information about groups refer to Groups
Section.
When creating or modifying a schedule.
Scheduled the Events.1.
Add a group which contains loads (relays) and 2.
their behaviors.
Example:
Name
What it
Controls
Its Behaviors
Schedule 1 Group 1
On 9am
Off 5pm
Mon-Fri
Group 1
LCP1:
relays 1-5
LCP2:
relays 3 & 9
When the group is “off ”,
relays may only be turned
on for 2 hours (relay-timer)
Prior to shutting lights off,
relays issue a blink warning.
To Navigate to Any Schedule (up to 32).
TAB to start.1.
TAB to REVIEW SCHEDULE and ENTER to 2.
select.
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
A list of the first 6 (of 32) schedules will be 3.
displayed. If needed SCROLL to the correct Page
SCHEDULES PAGE 1-6
Name: SCHEDULE 1
SCH 1 UNUSED
SCH 2 UNUSED
SCH 3 UNUSED
SCH 4 ===> NO LOADS
SCH 5 UNUSED
SCH 6 UNUSED
Page 1 of 6. SCROLL
to view more pages
“UNUSED” means
sch unprogrammed
“NO LOADS” means
sch is programmed -
no loads assigned..
TAB to a new or existing SCHEDULE and 4.
ENTER to select.
TAB to EVERY DAY (default) and SCROLL to 5.
select one of three schedule types:
Every Day.1.
Mon-Fri, Sat Sun.2.
By Day.3.
For more information on the three schedule types
refer to Scheduled Types Section.
SCH 1 EXCEPT NONE
EVERY DAY
ON TIME: 09:00 AM
OFF TIME: 05:00 PM
SCROLL to adjust
EVERY DAY•
M-F, S, S•
BY DAY•
For Every Day or Mon-Fri-Sat-Sun Schedules:
TAB to each ON TIME and OFF TIME.1.
SCROLL to adjust the Scheduled Event (refer to 2.
“Scheduled Events” Section for more information).
To Add or to edit
Holiday Lists refer to
Holiday Section
SCROLL to adjust
Scheduled Event
SCH 1 EXCEPT NONE
EVERY DAY
ON DUSK -30mins
OFF DAWN +30mins
Every Day Schedule - same on & off times 7 days/wk.
SCH 1 EXCEPT NONE
MONDAY - FRIDAY
ON TIME: 09:00 AM
OFF TIME: 05:00 AM
SAT ON TIME: 11:00 AM
OFF TIME: 03:00 PM
SUN none
none
Tab to each Scheduled
Event and SCROLL to
adjust.
