OTHER SYSTEM / SET UP PROGRAMMING
Date, Time and Location
The DTC in the relay panel is astronomical, and
needs to know the date, time, and location.
enter new time/date
8:50:00 AM PAGE 1
27 June 2008 Fri
Time starts when
you... hit enter
assembled 3 jan 2008
To save your settings
TAB to here and
ENTER to select
In the DTC, navigate to: USER MENU > SETUP 1.
MENU > SYSTEM SET UP MENU > SET TIME
AND DATE.
TAB to the hour and SCROLL to select. Repeat this 2.
process for minutes, seconds, day, month and year.
TAB to “HIT ENTER” and ENTER to save 3.
settings.
To Set Location
In the DTC Clock navigate to USER MENU > 1.
SETUP MENU > SYSTEM SET UP MENU >
SYSTEM OPTIONS > SELECT LOCATION >
LIST OF CITIES.
SCROLL to select city or nearest city.2.
TAB to “HIT ENTER” and ENTER to save 3.
settings.
Detroit MI
latitude: 42 N
Longitude: 83 w
time zone:gmt-5
To accept the above
settings...hit enter
SCROLL to select
nearest city
To save your settings
TAB to here and
ENTER to select
Optional: If you cannot find any cities within several
hundred miles of your location, EXIT and go to
LATITUDE – LONGITUDE. Use a dependable
resource (internet, etc.) to locate your exact Latitude
and Longitude.
The Time Zone is the number of hours negative or
positive from Greenwich Mean Time (GMT). For
example: the North American Eastern Time Zone
is - 5 GMT, Central Time is - 6, Mountain Time is - 7,
Pacific Time is - 8, and Hawaii is -11.
DAYLIGHT SAvING TIME
The relay control panel will automatically adjust
its time setting forward and backward an hour to
account for Daylight Saving Time.
To disable Daylight Savings Time
Navigate to the Display Options screen: 1.
SETUP MENU > SYSTEM SETUP > SYSTEM
OPTIONS > DISPLAY OPTIONS.
TAB to Daylight Savings and SCROLL to select 2.
NO.
TAB to “HIT ENTER” and ENTER to save 3.
settings.
EXIT when complete.4.
Military Time: NO
Seconds Visible: YES
Daylight Savings: YES
Temperature F/C: F
RS-232 K-BAUD: 57.6
Modem mode: 0
Photocell mode: NEW
To save: HIT ENTER
Daylight Saving Time will now be disabled.
