Lighting Controls Blue Box LT Series User Manual

82 THE BLUE BOX LT PROGRAMMING
LCDBBP03Sept08
ADDITIONAL GROUPS PARAMETERS
To adjust Group Parameters such as Automatic On,
Group Timer, and Blink Warning, navigate to the
Group Parameters Screen:
USER MENU › GROUP LOADS.1.
SCROLL to the correct page and TAB select a 2.
Group to be edited).
TAB to MNTN + TIMER or MNTN + BLINK 3.
and ENTER to Group Parameters Screen.
or
TAB to MAINTAIN and SCROLL to MNTN
+ TIMER or MNTN + BLINK and ENTER to
Group Parameters Screen.
Automatic On/No Automatic On
AUTOMATIC ON (the default setting) means that
the Group will switch its relays on when the Group
is turned on. Example: Schedule 1 turns on Group 1
at 9:00AM. If AUTOMATIC ON is selected the relays
in Group 1 will all be switched on. AUTOMATIC ON
is recommended for large open areas, such as a sales
floor or open area office.
NO AUTOMATIC ON means that the group will
not automatically switch relays on when the group
is turned on. Example: Schedule 1 turns on Group
1 at 9:00AM. If NO AUTOMATIC ON is selected.
the relays in Group 1 will not be automatically
switched on. Instead relays are turned on by a local
digital control station. NO AUTOMATIC ON is
recommended for smaller offices which have local
digital control stations.
TAB to AUTOMATIC ON.1.
SCROLL to change to NO AUTOMATIC ON.2.
Relay/Group Timers
All relays in a Maintain + Timer or Maintained + Blink
group have an “after-hours” timer value when the
group is switched off (usually by a time schedule) the
timer duration can be adjusted.
TAB to MNTN + TIMER, and ENTER.3.
GROUP1 PARAMETERS
AUTOMATIC ON
SET TIMER
TAB to SET TIMER and ENTER to program 4.
the after-hours relay timers. This features allows
occupants to switch lights on if the Group is off,
but only for the timer duration. This is an energy
savings feature required by most energy codes.
TAB to the Hours/Minutes/Seconds display 5.
and TAB/SCROLL to set the Hours/Minutes
and Seconds of the after-hours timer. 2:00:00 is
usually recommended. This will determine how
long relays are allowed to be “overrided” to the
“on” state before the timer runs out.
TIMER SETTING
REGULAR TIMER MODE
30:59:59 H/M/S
BLINK ONE: 05:00 M/S
BLINK TWO DISABLED
“Blink Timer” is only displayed, in a Maintain+
Blink Group. The default setting of 5 minutes gives
occupants 5 minutes after a “blink” warning to activate
an override (Momentary On, Toggle, or Momentary
On) switch before lights are shut off.
If during that 5 minute period, an “on” button is
pressed, all relays controlled by that button will be
extended for the duration of the timer (02:00:00
for example), and will again blink at that end of that
period. This process repeats itself every time the
override switch is activated until the next scheduled
On Time.
After Hours Timer is
for all relays in this
Group - relays will be
in a Timer-Mode to
conserve energy
BLINK is only for
MNTN+BLINK group
TIMER SETTING
REGULAR TIMER MODE
30:59:59 H/M/S
BLINK ONE: 05:00 M/S
BLINK TWO DISABLED
