Lighting Controls Blue Box LT Series User Manual

THE BLUE BOX LT PROGRAMMING 81
LCDBBP03Sept08
For more information on groups, please refer to the
Groups FAQ.
PROGRAMMING GROUPS
To Access a Group
Within the DTC, there are two paths you can use to
access a group for programming purposes:
From USER MENU:
Navigate to: USER MENU>GROUP LOADS 1.
and ENTER.
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
SCROLL to the correct page. (1 through 6) and 2.
TAB to the desired GROUP. ENTER to begin
editing or creating the desired GROUP.
GROUPS PAGE 1-6
GROUP 1 UNUSED OFF
GROUP 2 UNUSED OFF
GROUP 3 USED MOM
GROUP 4 USED ON
GROUP 5 USED ON
GROUP 6 UNUSED OFF
This group does not
have any loads
Momentary Group
This Group has loads
and is on
TAB to a group and SCROLL up or down to change the
status. Enter to edit the group
From the SCHEDULE MENU:
Schedule 1 is
programmed and has
no loads
Schedule 3 is not
programmed
Schedule 4 is
programmed and
controls GROUP 4
Schedule 6 is
programmed, but is
disabled
SCHEDULES PAGE 1-6
Name: SCHEDULE 1
SCH 1 ==> NO LOADS
SCH 2 UNUSED
SCH 3 UNUSED
SCH 4 ==> GROUP 4
SCH 5 UNUSED
SCH 6 ==> DISABLED
After creating, exiting, and saving a schedule, TAB
DOWN once to NO LOADS, or GROUP X (X
represents a number 1-32). ENTER to edit or create
the GROUP.
To Edit a Group
1. SCROLL to select the desired GROUP Type.
GROUP1 MAINTAIN
EDIT: LCP-1 LOAD-1
Add or delete loads.3.
EXIT when complete.4.
