Lighting Controls Blue Box LT Series User Manual

90 THE BLUE BOX LT PROGRAMMING
LCDBBP03Sept08
Set-up a third schedule to sweep-on the entry lights,
in case they were not manually switched on by a
control station. Note that this schedule simulates a
momentary push button and only turns the lights on.
Name Controls Behaviors
Schedule 6 Group 4
On 8:45am
Off 8:46Am
Every Day
Group 3
LCP1:
relays 1-7
Momentary On
Provide a button on a control station that 3.
switches on the “entry” lights on the morning
(On Mode).
Program another button on the same station to 4.
allow the last person out to switch off all lights.
Address 6 has
been named
the Entry Switch.
(Refer to Naming
Switches).
SWITCHES PAGE 1-2
#5: 14 BTN SW 5
#6: ENTRY SWITCH
#7: SWITCH 07
#8: SWITCH 08
Select ON MODE
(refer to Control
Types)
Add LCP 1: 1-7
SWI ID06-2 ON MODE
EDIT: LCP-1 LOAD-8
LCP1:1-8
A second control station in the managers office can
extend other lighting zones for after hours activities,
such as a photo-shoot, or extended store hours.
Tip: Check out our set-back Thermostats. They can
be locally and remotely programmed through the
Blue Box and can generate a very high Return On
Investment.
