LINET Sprint 100

D9S001ES1-0101 15
3.4.3 Types of siderails
Sprint 100 might be equipped with two types of siderails - with or without a „Soft Drop“ function. The version with the „Soft Drop“ func-
tion is equipped with gas spring in the middle of siderail mechanism. Gas spring is secured with starlocks. In the siderail attachment
are steel springs. Steel springs are greased.
Fig.19 Right siderail with Soft Drop (S6016530)
5+1 Nm
