LINET Sprint 100 Service Manual

D9S001ES1-0101 7
3.1.3 Undercarriage with hydraulic columns
Fig.5 Undercarriage (S6015633)
Fig.6 Fixed hydraulic column - detail (S6015633)
6+1 Nm
6+1 Nm
CAUTION!
Material damage due to incorrect use or during service!
► Do not use pedals for lifting or lowering if the bed is not in horizontal position!
► In case of replacing of the column the liquid in the new column (or when the bed was placed on the side) can be mixed
with air! It is necessary to remove the air from column for correct function!
To remove air from the hydraulic column perform procedure:
► press Lifting pedal 10 times in the highest bed position
Hydraulic unit is not divisible part. One hydraulic unit is one spare part
