D9S001ES1-010128
In the DIAGNOSTICS menu, the following parameters and their values are shown on the display:
Position Parameter Position Parameter
1 Numbering T1- T4 (0 - 3) 5 Total weight on tensometers
2 Current status of tensometers 6 Factory zero value
3 Weight in grams on individual tensometers 7 Gravitational constant value
4 Standard deviation in grams 8 Number of calibrations
5.1.3 Enabling selection of weighing units (kg / lb)
In the UNITS menu, it is possible to enable which weight units can be selected by the user (a nurse) by pressing the kg/lb button
on the display module keyboard.
To access the UNITS mode from the unlocked main menu (to unlock the menu, see chapter 5.1):
► Select UNITS using the PLAY/STOP or PAUSE button
► Confirm your selection by pressing WEIGHT/CLEAR button
► Use the PLAY/STOP and PAUSE buttons to select the desired unit
► Confirm your selection by pressing WEIGHT/CLEAR button
► ON/OFF is displayed at each unit
5.1.4 SW and HW versions of LW20 components
SW and HW versions of LW20 components can be displayed in the VERSIONS menu.
To access the VERSIONS mode from the main menu (to unlock the menu, see chapter 5.1):
► Select VERSIONS using the PLAY/STOP or PAUSE button
► Confirm your selection by pressing WEIGHT/CLEAR
