D9S001ES1-0101
24
Scale system error code
(letter F)
Meaning
0x40
At least one of the tensometers damaged
0x80
At least one of the tensometers dangerously damaged (mechanical
damage, bed not safe)
0x100
Calibration error
0x200
No local geographic zone is set
0x400
The local altitude zone is not set
0x800
T
ensometers measurement error
0x2000
Wrong type of scale module
0x4000
Non-volatile memory error
0x8000
Scale module not detected
