Lippert Components ground control TT User Manual

5
lci1.com 574-537-8900 Rev: 03.02.21
Ground Control
®
TT
Leveling OneControl
®
Touch Panel (3K-5K)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002700
Callout Part# Description Qty.
X 406345 OneControl Touch Panel 1
Y
191021 Hex Washer Head Screw, 3/8” - 16 x 1” 8
Z
118076 Bolt, 1/2” - 20 x 1 1/2” 12
AA
663511 Flange Bolt, 3/8” - 16 x 1 1/2” 12
AB 690759 Wood Screws, #8 x 1” 4
AC
241940 Self-Drilling Square Head Screws, #8 4
AD
206614 Hex Cap Screw Bolt, 3/8” - 16 x 3 1/2” 4
AE
378272 Carriage Bolt, 5/16” - 18 x 1” 12
AF
119075 Flat Washer, 3/8” 4
AG
119072 Serrated Flange Nut, 3/8” 4
AH
117891 Serrated Flange Nut, 5/16” 12
AI
178210 Serrated Flange Nut, 1/2” - 20 12
AJ 365417 Hex Serrated Flange Nut, 3/8” - 16 12
Callout Part# Description Qty.
N 425585 4 Pin Pigtail Harness 1
O
305115 Hall Effect Right Rear Sensor Harness 1
306298 Hall Effect Left Rear Sensor Harness 1
307489 Hall Effect Right Front Sensor Harness 1
307490 Hall Effect Left Front Sensor Harness 1
P
426526 Power and Ground Supply Harness 1
Q
421372 Power and Ground Supply Harness 1
R
331116 Canbus Data Harness 1
S
243688 Leveling Sensor Harness 35’ 1
T
329080 Canbus Power Connector Harness 1
U
423094 Leveling Sensor 2
V
433632 Blue Controller SE 1
W
425306 Auto Leveling Control Touch Pad 1
Parts List Continued
NOTE: Part numbers are shown for identification purposes only. Not all parts are available for individual sale.
All parts with a link to the Lippert Store can be purchased.
N O P Q R
S T
U V
W
X
Y Z
AA AIAB AC AD AE AF AG AH AJ
