lci1.com 574-537-8900 Rev: 03.02.21
Ground Control
®
TT
Leveling OneControl
®
Touch Panel (3K-5K)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002700
Callout Part# Description Qty.
H 671102 Bolt On Spacer Bracket 2
I 671294 Center Tube 38” x 2” x 1” 1
J 675725 Leveling Sensor Mounting Plate 2
K
671292 Bolt On I-beam Mounting Bracket 2
L
349975 Bolt On Bracket for 8” and 10” I-beam 2
M
333041 Canbus Terminating Resistor 2
Parts List
NOTE: Part numbers are shown for identification purposes only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
NOTE: Parts list continued on next page.
Callout Part# Description Qty.
A 421366 Power Tongue Jack 1
B
404488 3K C-Jacks 2
C
428493 5K Short Right-Hand Jack 1
D
342610 5K Short Left-Hand Jack 1
E
116112 Scissor Jack Crank Handle 1
F
428191 TT Leveling Ground Control Label 1
G
688837 GC One Touch Self-Level Label 1
A
B C D E F
G
H I J K L M
To Next Page
