LiteOn ISA-7-040-S1

Lite-On Technology Corp.
Industrial Automation
109
PA-16
ISP3
Internal Speed Command 3/Internal Speed Limit
3
Communication
address:
0020H
0021H
Initial value
30000
Control mode
T / S
Unit
0.1 r/min
Configuration
range
-50000 ~ +50000
Data size
32bit
Data format
Dec
Internal Speed Command 3: The setting of the internal torque command in the third segment (SPD0,SPD1) =
(1,1).
Internal Speed Limit 3: The setting of the internal torque limit in the third segment (SPD0,SPD1) = (1,1).
PA-17
(S-off)
CVM
The maximum rotation speed of the analog speed
command
Communication
address:
0022H
0023H
Initial value
By Rated
Control mode
T / S
Unit
r/min
Configuration
range
0 ~ max. Speed
Data size
16bit
Data format
Dec
Maximum rotation speed of the analog speed command:
 In the speed mode, this indicates the setting of the rotation speed while the maximum voltage (10V) is input
for the analog speed command.
If the speed is set to 3000 and 10V is input for external voltage, the speed control command is 3000r/min. 5V
implies that the speed control command is 1500r/min.
Speed control command = Input voltage value x Setting value/10
 In the torque mode, the parameter represents the command for analog speed limit.
Speed limit command = Input voltage value x Setting value/10
