LiteOn ISA-7-040-S1 - Page 151

Lite-On Technology Corp.
Industrial Automation
151
PC-20).
PD-43
TSPD
The level for the detection of the target rotation
speed
Communication
address:
0356H
0357H
Initial value
The rated value
Control mode
ALL
Unit
r/min
Configuration range
0 ~ 5000
Data size
16bit
Data format
Dec
The digital output (TSPD) is enabled when the speed reaches to the preset target speed. If the clockwise and
counterclockwise rotation speed of the motor exceeds the setting value, the target speed signal is formed and the
output pin is enabled.
PD-44
RegMisc1
The write-in of the special parameter
Communication
address:
0358H
0359H
Initial value
0
Control mode
ALL
Unit
N/A
Configuration range
0 ~ 0xFFFF
Data size
16bit
Data format
Hex
Settings:
Parameter
code
Function
4
Parameter reset (Power needs to be reconnected after
reset.)
6
Activation of the compulsory DO mode
106
After the compulsory DO mode is activated, it is possible
to switch back to the normal DO mode.
