LiteOn ISA-7-040-S1 User Manual

Lite-On Technology Corp.
Industrial Automation
86
Parameter
Abbr.
Function
Initial
value
Unit
Control mode
Remark
P
S
T
PB-29
GCM
Condition of the gain switch and the
selection for the switch method
10
O
O
O
PB-30
GCT
The time constant for the gain switch
1
10ms
O
O
O
PB-31
GCC
The condition of the gain switch
0
Pulse,
Kpps,
rmin
O
O
O
PB-32
AUTB
The setting for the response bandwidth of
the speed loop in the automatic and semi-
automatic modes
80
Hz
O
O
O
PB-33
AUTM
The method for gain adjustment
0
O
O
O
N-keep
PB-35
GSI
The ratio of load inertia to servo motor
inertia
0
0.1
times
O
O
O
PB-36
VSF1
Frequency for the vibration suppression of
low frequency (1)
1000
0.1Hz
O
PB-37
VSG1
Gain for the vibration suppression of low
frequency (1)
0
dB
O
PB-38
VSF2
Frequency for the vibration suppression of
low frequency (2)
1000
0.1Hz
O
PB-39
VSG2
Gain for the vibration suppression of low
frequency (2)
0
dB
O
PB-40
KPI
The integral compensation of the position
0
Hz
O
O
O
PB-41
JSL
The level for the stability determination of
inertia estimation
15
1 times
O
O
O
PB-42
AVSM
PB-43
VCL
PB-44
NCBW1
PB-45
NCBW2
PB-46
NCBW3
PC-00
DIRT
The time for response filtering of the
digital input
2
2ms
O
O
O
PC-01
DI1
The function planning for Pin DI1 of the
digital input
Based on the
control mode
O
O
O
PC-02
DI2
Function planning for Pin DI2 of the
digital input
Based on the
control mode
O
O
O
PC-03
DI3
Function planning for Pin DI3 of the
digital input
Based on the
control mode
O
O
O
PC-04
DI4
Function planning for Pin DI4 of the
digital input
Based on the
control mode
O
O
O
PC-05
DI5
The function planning for Pin DI5 of the
digital input
Based on the
control mode
O
O
O
PC-06
DI6
The function planning for Pin DI6 of the
digital input
Based on the
control mode
O
O
O
PC-07
DI7
The function planning for Pin DI7 of the
digital input
Based on the
control mode
O
O
O
PC-08
DI8
The function planning for Pin DI8 of the
digital input
Based on the
control mode
O
O
O
