LiteOn ISA-7-040-S1 User Manual

Lite-On Technology Corp.
Industrial Automation
87
Parameter
Abbr.
Function
Initial
value
Unit
Control mode
Remark
P
S
T
PC-09
DI9
The function planning for Pin DI9 of the
digital input
Based on the
control mode
O
O
O
PC-10
DO1
Function planning for Pin DO1 of the
digital output
Based on the
control mode
O
O
O
PC-11
DO2
Function planning for Pin DO2 of the
digital output
Based on the
control mode
O
O
O
PC-12
DO3
Function planning for Pin DO3 of the
digital output
Based on the
control mode
O
O
O
PC-13
DO4
Function planning for Pin DO4 of the
digital output
Based on the
control mode
O
O
O
PC-14
DO5
Function planning for Pin DO5 of the
digital output
Based on the
control mode
O
O
O
PC-15
DO6
Function planning for Pin DO6 of the
digital output
Based on the
control mode
O
O
O
PC-16
PC-17
PC-18
PC-19
PC-20
ZSPD
The level for zero speed detection
100
0.1 r/min
O
O
O
PC-21
BTOD
The turn-on delay time for the
electromagnetic brake
0
ms
O
O
O
PC-22
BTCD
The turn-off delay time for the
electromagnetic brake
0
ms
O
O
O
PC-23
SPOK
The level for detection of the speed
comparison
10
r/min
O
PC-24
PC-25
POL
The output level for the expected overload
0
%
O
O
O
PD-00
ADR
The setting of the branch number
7F
O
O
O
(Re-on)
PD-01
BRT
The communication transmission rate
33
O
O
O
PD-02
PTL
The protocol
6
O
O
O
PD-03
CFP
The handling of the communication error
0
O
O
O
PD-04
COT
The setting for the communication
timeout
0
sec
O
O
O
PD-05
PD-06
SWDI
Control switch for the source of the input
contact (DI)
0
O
O
O
PD-07
CDT
The time for the delay of the
communication response
0
1ms
O
O
O
PD-08
PD-09
PD-10
PD-11
VER
The firmware version
The factory
setting
O
O
O
(R-only)
PD-12
PD-13
PD-14
