Top part
The top part of the Quality Record page is devoted to text information. It is
subdivided into sections which group related parameters together. The following
list explains what each parameter means. More information is available in the
relevant manual sections.
Section ”Sensor Info”
Sensor type:
The sensor’s official type designation.
Part number:
LMI Technology’s part number.
Serial number:
The serial number of this particular sensor.
Date:
The date when the Quality Record was printed.
Operator:
The name of the person who was responsible for
preparing this sensor for delivery.
Signature:
The operator’s personal signature.
Section ”Parameters”
Measurement Range:
The nominal Measurement Range for the sensor
type. The actual Measurement Range for each
individual sensor may be different from the
nominal value by as much as shown by the
tolerance indication in parenthesis.
Mounting Standoff:
The nominal Mounting Stand-Off for the sensor
type. The actual Mounting Stand-Off for each
individual sensor may be different from the
nominal value by as much as shown by the
tolerance indication in parenthesis.
Scale Factor:
The nominal Scale Factor for the sensor type.
The actual Scale Factor for each individual sensor
may be different from the nominal value by as
much as shown by the tolerance indication in
parenthesis.
Outputs:
The output interfaces available in this sensor.
Explanations below for information about these
different interfaces.
Sampling Frequency:
The basic rate of raw data collection in this sensor
(see Explanations section below).
Bandwidth:
The bandwidth of this sensor.
Special tests:
Some sensor types for specific applications must
e put through special tests, which are not
compulsory for all sensors. The operator must
check one of these two boxes to indicate whether
such tests are required, and if so that they have
been carried out.
Section ”Laser Safety
