LMI Selcom SLS 5000 - Technical Description; Identification of Parts; Sls5000; Sls 6000

03-09-05 4
2 TECHNICAL DESCRIPTION
Identification of parts
SLS5000
Figure 1: Identification of parts SLS 5000
SLS 6000
Selcom
LASER MEASUREMENTS
SLS 6000
DANGER
Laser
Class 3B
Laser emitting
label
Air purge inlet Mounting Holes
M8 (4X), top mount
Receiver ApertureLaser aperture, incl laser shutter
Manufactures serial
number label
Emission indicator:
1.Illuminated when power is on
2. GREEN when target is within
the measurement range.
3. YELLOW when no target is present
within the measurement range.
Figure 2:SLS 6000
Mounting holes
SELCOM
SLS5000
Laser emitting
lable
Laser aperture
Receiver aperture
Emission indicator device
1, Illuminated when power is ON
2, Green when target is within the
measurment range
3, Yellow when no target is present
within the measurment range
Front glass
Side vie
w
Front view
Laser shutte
r
Manufacturers serial
number label
