Appendix E, Connection table
Cable-Terminal ends
COLOUR Terminal ends SIGNAL TYPE
BROWN 1 RxD
YELLOW 9 TxD
GREY 3 CLK/RX+
PINK 4 INV. CLK/RX-
BLUE 5 DATA/TX+
RED 6 INV. DATA/TX-
WHITE/YELLOW 12 INV OUT +
WHITE/GREEN 13 ANALOG OUT
YELLOW/BROWN 14 LASER ON (+24 v)
BROWN/GREEN 8 INV. OUT -
RED/BLUE N.C.
BLACK N.C.
VIOLET N.C.
GREY/PINK 15 + 24 V POWER SUPPLY
WHITE + GREEN (2
CABLES)
11 GND
SHIELD CONNECTOR
HOUSING
