Lockformer Vulcan 2900 - Vulcan 2900 Reference Photo

Vulcan 2900
REFERENCE PHOTO
"X" AXIS
DRIVE MOTOR
"X" CARRIAGE
("X" AXIS DRIVE)
FLOATING HEAD
PNEUMATIC
TORCH LIFTER
PLASMA TORCH
"X" BEAM
Y-2 EMERGENCY
STOP
"X" AXIS
RACK GEAR
"X" AXIS
SUPPORT ROD
CONTROLLER
PRECISION
BEARING
SUPPORT ROD
Y-2 RAIL
PROTECTED
CABLE TRACK
Y-1 RAIL
Y-RAIL SPREADER
"Y" AXIS DRIVE
PRECISION LINEAR
BEARINGS
"X" AXIS GANTRY
WELDMENT
"Y" AXIS
RACK GEAR
X-AXIS HOME
SWITCH
X-AXIS HOME
PLATE
Y-AXIS HOME
PLATE
Y-AXIS HOME
SWITCH
