FLASH PROGRAM
Instructions to Install New Table Set-Up Software
1. Double click on the left mouse button, OS/2 full screen, insert the disk labelled "Table Set-Up Diskette #1"
into drive A and type A:INSTALL and press Enter. Wait for 60 seconds and the screen will change and follow
instructions.
2. Turn the power off then back on as requested after INSTALL is complete.
Computer Set-Up
To flash the controller with the new operating system, both the office computer and the controller at the machine
must be configured as follows:
1. Before flashing the controller shut down either VDOWNLOAD or COMMUNICATIONS PANEL 2 Icon.
A. Close VDOWNLOAD by double clicking the left mouse button on the VDOWNLOAD icon. Make sure
caps lock is on and press "Q".
B. Close COMMUNICATIONS PANEL 2 by clicking the left mouse button once on the COMMUNICATIONS
PANEL 2 Icon and choose CLOSE. When asked if it is OK to shut down all communication programs,
click on OK.
2. Double click the left mouse button on the TABLE SETUPS icon to start the Flash Programmer.
3. Set the Baud Rates to 38400 by using the arrow keys.
4. Use the tab key to change to Com Port.
5. Configure to Com 1, or select Com 2 if using the Austin computer. Place an X in the Use CTS box by pressing
the spacebar.
6. Press the tab key to change to Download Event Symbols and place an X in the small box by using the
spacebar.
7. Press the tab key to change to Download WorkFiles and place an X in the small box by using the spacebar.
8. Press the "F" key:
Select the amc .hex file using the arrow key and press Enter.
Select the lf29 .ini using the arrow key and press Enter.
Select the eventsub.gpl using the arrow key and press Enter.
Select the workfiles by using the space bar and down arrow key to tag each one. After tagging all the
workfiles press Enter.
After selecting the five files configure the control at the machine.
Controller Configuration
1. Power up the controller.
2. Use the down arrow key and press F2 to select Interface. Press F3 to select GPS and press the ESC key.
3. Press the down arrow key until Load F/W. Press F1. If Baud Rate 38400 appears, press the ESC key and
return to the office computer. Otherwise, press the GO HOME key then the up arrow key and select 38400.
Press ESC.
Now the controller is configured. Return to the office computer and press the Enter key to start the
Flash. After the flash has been completed press ESC. To exit the Flash program do a normal computer
shut down and re-boot the computer.
