Lode BV Excalibur Sport
15
5. confirmation button
6. ergometer type indication
2.3 Control panel Excalibur Sport with Programmable Display (option
928811)
The control panel at the front side is as described in 2.2. Besides that the other side of the
programmable control panel consists of the following elements (Fig 8):
1. Display B (4x20 characters) directed to operator
2. Infrared window (only active for option 928820)
3. One-step-back button
4. Down button
5. Up button
6. Confirmation button
Fig 8: Control Panel Excalibur Sport with Programmable
Display
