Lode BV Excalibur Sport
21
4.2 Analog external control
Execute the following steps to control the Excalibur Sport externally using the analog in-/output:
1. Connect the external controlling device (e.g. ECG system) with a correct cable to the
analog i/o port (see 2.4 Back panel). Be sure to use the correct cable for connecting the
ergometer to an external (e.g. ECG) device. If you are not sure, please contact your
supplier.
2. Restart the ergometer and select ANALOG in the main menu.
3. Now the ergometer can be controlled by an external device with an analog signal.
The Excalibur Sport is now ready for external control.
For a technical description of the analog in-/output of the Excalibur Sport, see 8.4 Analog in/out
of this user guide.
During cycling, the display of the control panel shows the same information as described in
manual control.
4.3 Terminal – digital external control via RS232
For digital external control using the RS232 serial port execute the following steps for the
basic Excalibur Sport:
1. Connect the Excalibur Sport to the external control device (i.e. ECG, PC) using a
correct RS232 cable (see 2.4 Back panel and 3.2 Options for PC cables and Appendix
E RS232 Connections for ECG specific available cables). If you are not sure whether
your ECG device can be connected to the ergometer or not, please contact your dealer.
2. Switch on the ergometer and select the menu TERMINAL on the display of the
control panel.
3. Be sure that the correct protocol has been selected under the menu SYSTEM
PARAMETERS / SETTINGS / RS232 PROTOCOL (see 6.4.7 RS232 Protocol )
P= 0W 0 rpm
ANALOG
P= 0W 0 rpm
TERMINAL
MAIN MENU
SYSTEM PARAMETE
