Lode 925900 - 8.2 Loop Connection; 8.3 RS232 Specifications

Lode BV Excalibur Sport
39
Pin no. Signal: Direction (from Excalibur
Sport):
Remark:
1 DCD -- connected to DTR (4) and
DSR (6)
2 TxD Outgoing to computer
3 RxD Incoming from computer
4 DTR -- connected to DCD (1) and
DSR (6)
5 GND
(floating)
--
6 DSR -- connected to DCD (1) and
DTR (4)
7 N.C. --
8 N.C --
9 N.C. --
8.2 Loop connection
It is possible to control several Excalibur Sport ergometers with one external device using
RS232. Connect the RS232-in connector to the external device. Connect the RS232-out
connector to the RS232-in connector of the following Excalibur Sport ergometer, and so on.
The maximum number of Excalibur Sport ergometers that can be connected in this way is 8.
Use the device number option in SYSTEM PARAMETERS to give each Excalibur Sport a
unique number. In this way each Excalibur Sportcan be controlled separately, using the LEM
software.
8.3 RS232 specifications
The setting of the RS232 port when the LODE PROTOCOL is used:
Baud rate : 9600
Parity : none
Data bits : 8
Stop bits : 1
Tab 1: pin layout RS232 connector
