Lode BV Excalibur Sport
45
The programmable side of the programmable display consists of the following elements (Fig
11):
1. Display B (4x20 characters) directed to operator
2. Infrared window (only active for option 928820)
3. One-step-back button
4. Down button
5. Up button
6. Confirmation button
B.3 Using the Programmable Display Unit
Check if the ergometer is properly installed.
B.3.1 Startup
In the display of the basic control panel the following appears for a few seconds:
The name Excalibur Sport is the ergometer name, this depends on your type. On the lower
line the version of the embedded software is shown. Followed after a few seconds by:
At the same time the Programmable Display Unit (Fig 11: Control Panel Excalibur Sport with
Programmable Display Unit, item 1) shows for a few seconds:
In case the Blood pressure option is available it is followed for approximately 1 second by the
text "BPM Initialized "thereby indicating correct operation of the BP device. The SpO
2
comes
together with the P-Display. When this option is available correct operation is indicated by
the text "SpO2 Initialized". In case the 0-Watt Start -up System is available the text "0 Watt
Initialized" is displayed indicating the 0-Watt Start -up System is detected When all three
options are installed the display shows:
LODE ERGOMETER
TBD
P= 0W 0 rpm
LODE
P-display
ver X.YZ
