Lode 925900 - RS232 Protocol Selection Procedure

85
Sensormedics
Vmax 29 P10
Vmax analog P10
Sensormedics Cardiosoft + Corina V4.2 P10
Sensormedics
Oxycon Pro Lode WLP
Oxycon Alpha Lode WLP
Oxycon Beta Lode WLP
Welch Allyn Cardio Control
Cardioperfect 2001 (CP comcard ISA) LODE Protocol
Cardioperfect 2001 (Unilink USB or CP comcard
PCI)
LODE Protocol
A Lode ergometer is default shipped with the LODE RS232 communication protocol. You
can change the RS232 protocol by following the procedure below:
• Switch on the ergometer and press enter.
• You will be in the "MAINMENU"
• Select, by using the up/down keys, the menu "SYSTEM PARAMETER" and press
enter
• Select, by using the up/down keys, the menu "SETTINGS" and press enter
• Select, by using the up/down keys, the menu "RS232 PROTOCOL" and press enter
• Select, by using the up/down keys, the desired protocol and press enter.
• Save the selected RS232 protocol or restore the default RS232 protocol, which is also
the LODE PROTOCOL.
• Switch off the ergometer.
