3. Gradually tighten the nuts on both sides to prevent misalignment.
01-00335-DM
4 x M12x140
4 x M12
4.
01-00335-DM
12 x M12x140
12 x M8
12 x
3x
5. Repeat steps 2 to 4 for the second rail pipe.
USER MANUAL
21
