Logosol B1651 - Mounting of the Platform & Toolbox

MOUNTING OF THE PLATFORM & TOOLBOX
1.
4 x M6x12
4 x M6
2 x
2. Please note the direction of the saw blade before mounting the platform. Lower the platform in place.
Attach the bolts to its sides and back. The assembly is symmetrical around the platform.
6 x M6x12
6 x M6
USER MANUAL
26
