MOUNTING OF THE SAW HEAD ON THE RAIL FRAME
Lift the saw head into place on the rail. The carriage and saw head weighs 350 kg in total. Use a sling approved
for the purpose and attach to the saw head’s lifting points. Lift the saw head using the appropriate lifting gear
IMPORTANT
The anti-tip wheels must be mounted on the underside of the saw carriage when the saw head
is mounted on the rail.
