MOUNTING OF THE SAW HEAD ON THE CARRIAGE
Steps 1-7 will be performed on both sides of the carriage simultaneously
WARNING!
Heavy lifting. Risk of injury.
1. Mount the shroud on the carriage.
1 x M12x40
2 x M12x32
3 x M12
1 x
USER MANUAL
46
