MOUNTING OF THE LOG TENSION PROFILE
1. Fit the log tensioning proles on the side of the cross bunk with no reinforcement. We recommend
installing the proles on cross bunk 1 and 3.
4 x
M8x20
4 x
M8
1 x
2.
3 x M8x14
3 x M8
1 x
