TECHNICAL DATA
LOGOSOL B1651
RAIL COMPONENT
Rail length, standard 6232 mm
Rail length, extension 1156 mm
Track width 1,75 m
Overall width 1,92 m
Height 240 mm
Weight (6,23 m rail) 500 kg
SAW CARRIAGE
Length 1,42 m
Width 2715 mm
Height 2850 mm +- 40 mm (support legs)
Weight 350 kg
Volume, water reservoir 25 liters
Feed rate Variable
CAPACITY
Max. log diameter 1651 mm
Max. sawing width 1500 mm
Effective saw length (standard) 4380 mm
BANDSAW BLADE
Type and size 5610x33 pitch 22 mm
Band wheel diameter 500 mm
Band wheel, rotational speed 1000 v/min
Saw blade, speed 30 m/s
SAW MOTOR(S)/ENGINE
Electric motor drive 12 kW, 400 V (Weight: 65 kg)
Fuse 25 A
Petrol engine Loncin 27hp
Volume, fuel tank 5 liters
NOISE LEVEL/VIBRATIONS
Equivalent sound pressure level at ear
of operator
a.
88,4 dB(A)
Sound power level (estimated)
b.
109,4 dB(A)
Vibration level in handle
c.
<2,5 m/s
2
a.
The typical distribution measurement for equivalent sound pressure level is a standard deviation of 2 dB(A)
b.
The typical distribution measurement for sound power level is a standard deviation of 3 dB(A)
c.
The typical distribution measurement for vibration level in the handles is 1 m/s2
USER MANUAL
11
