Lopi Answer - Alcove Installation Rules

PAGE 8 STOVE INSTALLATION (CONT.)
OPTIONAL EQUIPMENT REQUIREMENTS (See "Optional Equipment" starting on page 36
¥ Must be installed with either the optional legs or pedestal
FACTORY BUILT CHIMNEY REQUIREMENTS
¥ Chimney connector must be a minimum 24 MSG black or 26 MSG blued steel
¥ Use 6" diameter type HT chimney from one manufacturer (do not mix brands). Chimney must
be used from the first floor or wall penetration to the chimney cap.
¥ Chimney connector and chimney must be fastened to the stove and each adjoining section
¥ Follow the chimney manufacturer's clearances and requirements
¥ Use the chimney manufacturer's fire stops, attic guards, roof supports, and flashings when
passing through a ceiling (or thimble when passing through a combustible wall)
¥ Minimum height of 15 feet
NOTE: External factors may adversely affect draft (see "Drafting Performance" below). In
these cases additional chimney height may be required to boost draft.
¥ Maximum height of 33 feet
¥ No more than 180
o
of elbows (two 90
o
elbows, or two 45
o
& one 90
o
elbow, etc.)
NOTE: Additional elbows may be allowed if draft is sufficient. Whenever elbows are used the
draft is adversely affected. Additional chimney height may be required to boost draft.
AA
AA
AA
A
A
A
A
A
A
A
AA
AA
AA
AA
AA
AA
AA
AA
Chimney Cap
(See the section
"Chimney Termination
Requirements" for
more details)
A
AA
AA
AA
AA
AA
AA
AA
Factory Built
Chimney
Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions - usually 2")
Floor Penetration
Equipment (Attic
Radiation Shield with
Chimney Support)
Reduceced
Clearance
Chimney
Connector
Sections
Roof Penetration Equipment
(Roof Radiation Shield,
Flashing, Storm Collar)
}
}
AAAAA
Floor
Protection
AA
AA
AA
AA
Stove Clearance
(as outlined in this manual)
A
A
A
A
A
A
A
A
A
AA
AA
AA
AA
AA
AA
AA
AA
AA
}
Standard residential installations with
reduced clearance connector may use the
clearance determined by the manufacturer
of the connector for the connector to wall
clearance or the clearance listed in this
manual.
Mobile home installations must use the
the reduced clearance connector
clearances listed in this manual under
ÒAdditional Requirements for Mobile Home
InstallationsÓ.
Minimum System 15'
Maximum System 33'
A
A
Drafting
Performance
This appliance relies upon natural draft to operate. External forces, such as wind,
barometric pressure, topography, or factors of the home (negative pressure from exhaust
fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries can
not be responsible for external forces leading to less than optimal performance.
