FEATURES AND SPECIFICATIONS PAGE 5
Installation Options:
¥ Freestanding
¥ Freestanding in an Alcove
¥ Freestanding in a Mobile Home
¥ Masonry Fireplace Insert
¥ Factory-Built (Z.C.) Fireplace Insert
Features:
¥ EPA Phase II Approved
¥ 1.6 Cubic Foot Firebox Volume
¥ Single, Push/Pull Operating Control
¥ Accepts Logs Up to 18" Long
¥ Long Burn Time - Up to 8 Hours
¥ 5/16" and 3/16" Steel Plate Construction
¥ Heavy Duty Refractory Firebrick
¥ Optional High-Tech Blower
Heating Specifications:
Approximate Maximum Heating Capacity (in square feet)* 750 to 1,400 (stove)
750 to 1,200 (insert)
Maximum BTU's per Hour (Cord Wood Calculation) 66,800
Overall Efficiency (Oregon Method) 70%
Maximum Burn Time (Hours) 8
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature. It is also
affected by the quality and moisture level of the fuel.
Dimensions:
23 5/8"
Weight (with legs):.....300 Lbs.
Flue Location:
Flue is centered on
the stove and 5 7/8"
from the back edge
of the appliance.
(Use 6" Dia. Pipe)
Height*:
Base to Top...................20"
With Black Steel Legs......26 1/2"
With Cast or Brass Legs...27 7/8"
With Pedestal.................31 7/8"
* For inserts, allow an additional
3/4" for the flue ring (see page 16)
**Zero Clearance Fireplaces require 14 1/2" (see page 16)
*** Does not include hearth protection (see page 16)
Depth:
From Back to Faceplate....16 1/4"
Into Fireplace**...............13 1/2"
Onto Hearth***................3"
Ashlip Depth...................4 3/4"
Emissions: 3.3 Grams Per Hour (EPA Phase II Approved) Ð Tests conducted by E.E.S.P.C. Lab.
