STOVE INSTALLATION (CONT.) PAGE 11
MOBILE HOME REQUIREMENTS
The Answer is approved for installation into a mobile home if the requirements listed below are met in
addition to the normal requirements:
¥ Outside air must be installed - see "Outside Air Requirements" on page 9
¥ The appliance must be bolted to the floor (The optional pedestal provides the equipment needed
to do this - see "Pedestal Installation" on page 36)
¥ The appliance must be grounded to the chassis of the mobile home (some states do not require
this Ð check with local building officials)
¥ The appliance must not be located in the bedroom of a mobile home (some states do not require
this Ð check with local building officials)
¥ Chimney connector and chimney must be one of the following types:
¥ DURAVENT model DVL with DURA-PLUS chimney
¥ AMERI-TEC model DCC with model HS chimney
¥ SECURITY model DP with SECURITY model ASHT or S2100 chimney
¥ GSW model Super Chimney Twenty-One connected directly to appliance
¥ SELKIRK METALBESTOS model DS connector with model SSII chimney
¥ Standard Masonry Chimney with any one of the above listed connectors
¥ Stove placement must maintain the following clearances to combustibles (drywall, furniture, etc.)
Minimum Clearance(See the illustration below)
A Sidewall to stove
13"
B Backwall to stove
9"
C Cornerwall to stove
7 1/2"
D Connector to sidewall
21 1/2"
E Connector to backwall
11 1/2"
F Connector to cornerwall
16 1/2"
C
STRAIGHT
INSTALLATION
CORNER
INSTALLATION
A
B
D
E
A
D
F
C
F
Combustibles (drywall, wood, etc.)
Combustibles (drywall, wood, etc.)
NOTE:
Clearances are measured from the stove top.
