LORCH T 220 DC BasicPlus User Manual

Technical data
- 44 - 01.21909.2669.9-02
16 Technical data
Technical data* Units
Machine type
T 180 DC
BasicPlus
T 220 DC
BasicPlus
T 180 AC/DC
BasicPlus
T 220 AC/DC
BasicPlus
TIG welding
Welding range min - max
A 3 - 180 3 - 220 3 - 180 3 - 220
V 10,1 - 17,2 10,1 - 18,8 10,1 - 17,2 10,1 - 18,8
Idle voltage
(peak value in accordance with EN 60974-1)
V/DC 76 - 87 76 - 86 83 - 100 78 - 110
Current setting
Innitely
variable
Innitely
variable
Innitely
variable
Innitely
variable
Slope characteristic falling falling falling falling
Welding current at ED 100% A 130 160 130 160
Welding current at ED 60% A 150 180 150 180
ED at maximum welding current % 35 40 35 40
Current consumption I1 (at ED 100%) A 14,5 14,1 15,0 15,0
Current consumption I1 (at ED 60%) A 17,4 16,4 18,1 17,4
Current input I1 max A 22,4 22,2 23,1 23,5
Maximum eective mains current (I1e) A 14,5 14,1 15,0 15,0
Power consumption S1 (at ED 100%) kVA 3,3 3,2 3,5 3,5
Power consumption S1 (at ED 60%) kVA 4,0 3,8 4,2 4,0
Input power S1 max kVA 5,2 5,1 5,3 5,4
Electrode welding
Welding range min - max
A 10 - 150 10 - 180 10 - 150 10 - 170
V 20,4 - 26,0 20,4 - 27,2 20,4 - 26,0 20,4 - 26,8
Idle voltage
(peak value in accordance with EN 60974-1)
V/DC 83 - 106 82 - 96 83 - 100 82 - 98
Current setting
Innitely
variable
Innitely
variable
Innitely
variable
Innitely
variable
Slope characteristic falling falling falling falling
Welding current at ED 100% A 90 120 90 120
Welding current at ED 60% A 120 150 110 140
ED at maximum welding current % 35 40 35 40
Current consumption I1 (at ED 100%) A 14,5 15,1 15,2 15,9
Current consumption I1 (at ED 60%) A 20,0 19,9 19,1 19,3
Current input I1 max A 26,0 25,0 27,0 24,1
Maximum eective mains current (I1e) A 15,5 15,8 16,0 15,9
Power consumption S1 (at ED 100%) kVA 3,3 3,5 3,5 3,7
Power consumption S1 (at ED 60%) kVA 4,6 4,6 4,4 4,4
Input power S1 max kVA 6,0 5,8 6,2 5,5
Weldable electrodes mm 1,5 - 4,0 1,5 - 4,0 1,5 - 4,0 1,5 - 4,0

LORCH T 220 DC BasicPlus Specifications

General

Brand	LORCH
Model	T 220 DC BasicPlus
Category	Welding System
Language	English
