Mobile Apps: Accessing your DVR Using a Mobile Device18
18.3.3 Live View Interface
1
2
3 4 5 6 7 8 9 10 1112 13 14
1. Device List: Drag cameras to the display area to open a single camera. Drag a DVR to the display area
to open all cameras connected to that DVR.
2. Display Area: Tap a camera to select. Double tap to view a camera in full screen.
3. Show/Hide Device List.
4. Screenshot: Tap to take a screenshot from the currently selected camera.
5. Manual Recording: Tap to start recording the currently selected camera. Tap again to stop recording.
6. Clear/Fluent: Select Clear for the app to prioritize video quality over frame rate if the connection is not
fast enough. Select Fluent for the app to prioritize frame rate over video quality.
7. Favorites.
8. Disconnect/Connect: Tap to disconnect from/connect to the currently selected camera.
9. Disconnect/Connect All: Tap to disconnect from/connect to all cameras.
10. Split-screen: Select desired split-screen layout.
11. Previous Page: Tap to select the previous page of cameras.
12. Next Page: Tap to select the next page of cameras.
13. Full-screen: Tap to open the display area in full-screen. Tap again to exit full-screen.
14. PTZ Controls: Tap to open PTZ camera controls (PTZ camera required; not included).
18.3.4 Taking Screenshots
1. Tap
during live view or playback to take a screenshot from the currently selected
camera. To view snapshots, please refer to the section 18.3.8 Viewing Screenshots,
page 114.
18.3.5 Taking Manual Recordings
1. Tap
during live view or playback to start manual recording from the selected
camera.
2. Tap
again to stop recording. To view manual recordings, please refer to the sec-
tion 18.3.9 Viewing Manual Recordings, page 115.
#LX400012; r. 2.0/12066/12066; en-US
111
