Using the On-Screen Display
9
To use the Virtual Mini-Keyboard:
1. Using the Mouse, click on an option or field, such as the Time or Date fields.
• The Virtual Mini-Keyboard opens.
• Click to enter your selection.
9.3 Using the Zoom Mode
Zoom Mode allows you to zoom in on an image while viewing your cameras live. This can
be useful if you want to get a closer look at a situation.
To use the Zoom Mode:
1. In Live Viewing Mode, select the channel you want to zoom in on in full-screen (dou-
ble-click the channel if you are in a Split-screen View).
2. Right-click to open the Menu Bar and select the Zoom button (
). A Zoom icon ap-
pears on the screen.
2.1. Click and drag on the area of the screen you would like to enlarge. The image zooms in on the
selected area.
2.2. The box in the lower right-hand corner shows the entire camera picture with a black box around
the zoomed-in area. Click inside the box and drag to move the zoom area.
3. Right-click to exit and select a different zoom area. Right-click again to exit Zoom
Mode and return to Live Viewing Mode.
9.4 Using Picture in Picture (PIP) Mode
Picture in Picture (PIP) Mode allows you to view one channel in full-screen while viewing
up to two other channels.
To use Picture in Picture Mode:
1. Right-click to open the Menu Bar and select the PIP1X1 button (
) or PIP1X2 button
(
). PIP1X1 shows one channel in full screen and one other channel; PIP1X2 shows
one channel in full screen and two other channels.
#LX400012; r. 2.0/12066/12066; en-US
23
