Basic Setup (LH150 Series)
6
1. VGA port.
2. HDMI port.
6.5 Step 5: Connect the Power Adapter and Power on the DVR
1. Connect the included power adapter to the DC 12V port. Connect the end of the power
adapter to a wall socket or a surge protector.
2. Turn the power switch to I to turn on the DVR.
At startup, the system performs a basic system check and runs an initial loading sequence.
After a few moments, the system loads a live display view.
6.6 Step 6: Upgrade Firmware to Latest Version (if Available)
If a firmware upgrade is available, you will be asked to install it once the DVR starts up. It is
required to upgrade your system firmware and client software or mobile apps to the latest
version to enable remote connection to the system.
If a firmware upgrade is available:
1. After startup, a notification will appear asking you to upgrade the firmware. Click Yes to
upgrade.
#LX400012; r. 2.0/12066/12066; en-US
