Appendix A: System Specifications
Appendix A: System Specifications
General
Camera
LCD Receiver
Description Specification
Transmission Frequency ISM 2,400~2,483.5 MHz
Transmission Power 14dBm
Unobstructed Effective Range 450ft / 150 m (line of sight)
Spread Spectrum FHSS
Modulation Mode GFSK
Operating Temperature 14 ~ 122° Fahrenheit / -10 ~ +50° Celsius
Operating Humidity < 85%
Description Specification
Image Sensor CMOS
Total Picture Pixels 640 x 480pxl (NTSC)
Minimum Illumination 0Lux (IR on)
Night Vision Distance 40 FT
PIR Range 21 FT
View Angle Diagonal 52°
Power Consumption (Max.) Max 350mA
Power Supply 9V DC
Dimensions W: 75mm, L: 110mm, H: 190mm
Weight 0.60 lbs / 0.27 kg
Description Specification
Display 9" diagonal or 7‘diagonal (check package for display size)
Supported Resolution 640 x 480 @ 10fps or 320 x 240 @ 25fps
Receiving Sensitivity -81dBm
Power Consumption (Max.) 850mA
Power Supply 5V DC
