Appendix C: Adding Cameras
Appendix C: Adding Cameras
The system comes with camera(s) that have already been paired to the LCD receiver. The
Pairing Function assigns each camera to a different channel on the wireless receiver (up
to four (4) cameras), and is necessary for configuring additional cameras.
NOTE: T
o order additional cameras, order part number LW2711AC1.
By default,
the camera included with your system
is automatically paired to channel 1 on
the wireless receiver. The second camera is paired to channel 2 and so forth. See channel
label on the bottom of the camera to check which channel it has been set to .
It is highly recommended to pair the cameras to the receiver before permanently
mounting the
cameras.
To pair an additional camera:
1 Connect the new camera to a power outlet. Place the
ca
mera and LCD receiver within 1 ft of
each other.
2 Press MENU on
the wireless receiver or remote control.
3 From the Main Menu, select Pairing and pr
ess the Enter
button on the remote.
4 Select a channel and press the Enter butt
on on the
remote.
NOTE: If you pair a new camera to a channel which is already
being
used by an existing camera, the new camera will be connected to that channel.
The old camera will automatically be disconnected.
5 F
ollowing the on-screen prompt, press the Pair button
behind the camera. You have 30
seconds to press the Pair button on the camera. Once paired, the camera will be immediately
displayed on-screen.
NOTE: If you do press the Pair button on the camera during the 30 second pairing window,
repeat steps 2~5 to try the pairing process again.
