Using the On-Screen Display (OSD) Menu
1
SET NORTH Set the current viewing angle as the benchmark angle for the camera.
LANGUAGE Set the language for the OSD menu.
FACTORY DEFAULT Restore the camera system settings to their original, out-of-the-box state.
Exposure settings are not affected when you restore the camera system
settings.
RESTART Reboot the PTZ camera. OSD settings are not affected when you reboot
the camera.
1.1.1 System Information
Note
The information in this section is for service purposes only.
The system information menu displays the PTZ protocol information, including the camera
address, baud rate, parity, and firmware version numbers. The information in this section
is for reference and cannot be configured through the OSD menu.
1.1.2 Address (ADDR) Information
Note
The information in this section is for service purposes only.
The address information menu lets you choose how the camera address is determined.
The camera address is how standard definition DVRs identify PTZ cameras. Under ADDR
TYPE, select HARD to have the address determined by the DIP switches inside the cam-
era housing, or SOFT to select the address using the software (select the address value
under ADDR-SOFT).
1.1.3 Restore Factory Defaults
Restore the camera module to its out-of-the-box state. This will reset all menu items ex-
cept those in the CAMERA SETTING menu back to their default values.
#LX400027; r. 1.0/16996/16996; en-US
