Parking brake indicator (Red)
When the handbrake is not pulled up, the light is on, and the alarm flashes at a frequency of 1Hz.
Fig. 3-16 Parking brake indicator
Steering low voltage warning lamp (Red)
When this light is on, it indicates low steering pressure of tractor.
Fig. 3-17 Steering Low Voltage Warning Lamp
Traffic Safety Indicator (Red)
The light is not on when the driver steps on the clutch pedal to turn on safety start switch
and pulls the ignition lock to the Start position, and the engine is normally started on the
condition that the driver is on the seat,the vehicle is in neutral position, the hand brake is pulled
up, the PTO rocker switch is disconnected, and the control box is normally powered-on.
Fig. 3-18 Traffic Safety Indicator Light
The vehicle fails to be started, and the light is on and flashes at 1Hz when the driver starts the
vehicle and the vehicle is not in neutral position;
The vehicle fails to be started, and the light is on and flashes at 2Hz when the driver does not
start the vehicle from the seat;
The vehicle fails to be started, and the light is on and flashes at 3Hz when the driver starts the
vehicle and the PTO rocker switch is not disconnected.
Parking brake warning indicator (Red)
This light is on when the tractor is parked and the handbrake pulled up.
Important matters: when the tractor is working, the driver shall always pay attention to all kinds of instruments
and indicator lights, and shall park and overhaul immediately in case of abnormal situation.
